1000-Series Turbine Flow Meters

1000-Series Mini Turbine Flow Meters

The 1000 series turbine flowmeter is designed to give high performance and competitive pricing with 7 flow ranges from 0.05 to 30 L/min. Its choice of body materials makes this the ideal choice for the metering of aggressive chemicals, including ultra-pure water. The standard inlet is a ½” BSPF although for OEM use alternatives are available. The bearings are made of sapphire for long life and reliability, the body is either PVDF or 316 stainless steel and as standard the ‘O’ ring seal is Viton™.

Download the 1000 Series Flowmeter Datasheet

Would you like some advice?

If you would like some help selecting a Flowmeter, our experienced team are always happy to help.

Search for other Flowmeters:

SKU N/A Category

The 1000 Series Turbine Flow Meter is Ideal for:

  • Laboratory tests
  • Cooling equipment
  • Active flow alarms
  • Semiconductor plant
  • Engine test

Features:

  • Low cost
  • PVDF or St St Body
  • 1- 2% FSD
  • Sapphire bearings
  • Hall Effect sensor
  • 7 Flow ranges
  • Pulse output (NPN Standard; PNP Option)
  • 10 bar pressure rating (40 bar option)
  • Viton™ seal as standard
  • 0.1% Repeatability
  • 4.5 to 24 Vdc
  • -25°C Min to 125°C Max
  • IP65

Technical Data & Downloads

Technical Specification

ModelFlow Range
L/Min
Linearity
% FSD
Typical Frequency
Hz
Approx
'K' Factor
10030.05-0.52.014217000
10150.12-1.52.01757000
10450.20-4.51.52603500
10650.25-6.51.52302100
10100.30-10.01.02351420
10240.50-15.01.0245980
10002.00-30.01.0250500

Product Data Sheet – Specification & Order Codes

Product Instruction Manual

Technical Drawings – STP File

Installation

Trouble-free Installation and Commissioning of Your Flow Meter

Prior to installing the flow meter, read the Instruction Manual and refer to the following Installation Checklist to prevent avoidable failures due to mis-wiring etc.

For technical issues, refer to our Troubleshooting section or email technical@flowmeters.co.uk
