900-Series Turbine Flow Meters

900-Series Mini Turbine Flow Meter

The 900 series turbine flowmeter is designed to give high performance and competitive pricing with 6 flow ranges from 0.05 to 15 L/min. Its choice of body materials makes this the ideal choice for the metering of aggressive chemicals, including ultra-pure water. The standard inlet is ¼” BSPF although for OEM use alternatives are available (such as a ¼” NPTF option). The bearings are made of sapphire for long life and reliability, the body is either PVDF or 316 stainless steel and as standard the ‘O’ ring seal is Viton™.

Download the 900 Series Flow Meter Datasheet

Would you like some advice?

If you would like some help selecting a Flowmeter, our experienced team are always happy to help.

Search for other Flowmeters:

SKU N/A Category

The 900 Series Turbine Flow Meter is Ideal for:

  • Laboratory tests
  • Cooling equipment
  • Active flow alarms
  • Semiconductor plant
  • OEM Applications
  • Chemical dispensing / dosing

Features:

  • Low cost
  • PVDF or St St Body
  • 1- 2% FSD
  • Sapphire bearings
  • Hall Effect sensor
  • 6 flow ranges
  • Pulse output (NPN Standard; PNP Option)
  • 10 bar pressure rating
  • Viton™ seal as standard
  • 0.1% Repeatability
  • 4.5 to 24 Vdc
  • -25°C Min to 125°C Max
  • IP65

Technical Data & Downloads

Technical Specification

ModelFlow Range
L/Min
Linearity
% FSD
Typical Frequency
Hz
Approx.
'K' Factor
9030.05-0.52.014217000
9150.12-1.52.01757000
9450.20-4.51.52603500
9650.25-6.51.52302100
9100.30-10.01.02351420
9240.50-15.01.0245980



Data Sheet PDF (with order codes)

Instruction Manual PDF

Technical Drawings STP File

Installation

Trouble-free Installation and Commissioning of Your Flow Meter

Prior to installing the flow meter, read the Instruction Manual and refer to the following Installation Checklist to prevent avoidable failures due to mis-wiring etc.

Titan’s 900 Series Turbine Wiring Installation Tutorial (YouTube Video)

For technical issues, refer to our Troubleshooting section or email technical@flowmeters.co.uk
